產品中心 托盤專用打包機 TP-502MH Genesis Hori 半自動水平式打包機

TP-502MH Genesis Hori 半自動水平式打包機


Genesis Hori TP-502MH inherits all of the advantages from Genesis TP-502, such as compact strapping head, direct drive technology with German-made DC motors, and electronic tension control. It can be moved easily beside the load you want to strap without moving the pallet. The TP-502MH is quick, ergonomic, and economical solution for low volume horizontal pallet strapping applications.

Features

  • Compact mechanical strapping head
  • Adjustable strapping height
  • Electronic tension control
  • Jog switch
  • Adjustable weld-cooling time
  • Two moving direction



Options

  • Battery power supply (TP-502MHB)
  • Edge protector holder
  • Handle on the rear for back/forth movement



Technical Data

Strap Type PP strapping
Strap Width 9 mm, 12 mm, or 15.5 mm
Tension Range 8 - 70 kg
Weight 292 kg
Electrical Requirements 110V, 220V, 230V, 240V 50/60Hz 1PH
TRANSPAK全系列產品皆於品質管理系統 (ISO 9001) 認證的台灣工廠製造
